Safety PLC Integration Patterns

Safety automation modules featuring seamless integration with existing safety PLCs for enhanced system efficiency.

Plants do not want experimental safety architectures. They want a safety system that integrates cleanly with existing safety PLCs, safety relays, and downstream interlocks.

The integration question is simple: when SR-1 detects an entry into a defined zone, what output does the safety controller receive, and what does it do next?

A clean integration includes:

• Clearly defined safety outputs (stop / reduced speed / safe state)

• Deterministic behavior (same input → same result)

• Diagnostics and fault handling that drive safe behavior

• Commissioning steps that validate performance and document results

SR-1 is designed to integrate into standard safety architectures. You define:

• Which zones map to which safety outputs

• How outputs latch or reset (per risk assessment)

• What the cell does in each state (slow, stop, inhibit motion)

This approach keeps the safety function understandable for integrators and auditable for EHS.

Talk to an expert. Share your PLC/controller and we’ll outline a practical integration pattern.
